1. Servomotor drive, supporting tensile force sensor, real-time monitoring of the friction resistance during the test. When the resistance exceeds the set value, the system outputs an alarm and stops the test. 2.
2. fully automatic simulation of the test starting point and end point, reversing direction with flexible buffer deceleration function, so that the reversal is smooth and reliable. 3. programmable sectional and speed loading. 3. the loading process can be programmed in segments and speeds.
4. motorized adjustment of horizontal loading height, any position self-locking holding position.
GW-BFM-24
Great Win
9024800000
| Quantity: | |
|---|---|
Product Characteristics |
1. Servomotor drive, supporting tensile force sensor, real-time monitoring of the friction resistance during the test. When the resistance exceeds the set value, the system outputs an alarm and stops the test. 2.
2. fully automatic simulation of the test starting point and end point, reversing direction with flexible buffer deceleration function, so that the reversal is smooth and reliable. 3. programmable sectional and speed loading. 3. the loading process can be programmed in segments and speeds.
4. motorized adjustment of horizontal loading height, any position self-locking holding position.
BRAND | Great Win |
ITEM NO. | GW-BFM-24 |
ORDER(MOQ) | 1 |
PAYMENT | TT OR L/C |
PRODUCT ORIGIN | China |
SHIPPING PORT | Shenzhen Port |
LEAD TIME | In stock, 7days Fast Delivery |
| Technical Specifications |
| Parameter | 1. can set the guide rail travel: 80-580 mm, can set the maximum push and pull speed: 400 mm / sec. 2. Maximum push and pull force alarm output can be set: 0-25kg force. 3. Motorized adjustable horizontal loading height: 200-1600 mm, self-locking at any height position. 4. Overall dimensions: 1200 * 850 * 1970 mm, 177 kg; Power supply: 220VAC 5A. |
| Control | 1. PLC control, touch screen input test parameters and output test and results. With stop break point memory function. 2. Adopting Panasonic AC servo motor drive, supporting pull pressure sensor. Real-time tracking amount to display the movement position and the size of push and pull force. |
Product Characteristics |
1. Servomotor drive, supporting tensile force sensor, real-time monitoring of the friction resistance during the test. When the resistance exceeds the set value, the system outputs an alarm and stops the test. 2.
2. fully automatic simulation of the test starting point and end point, reversing direction with flexible buffer deceleration function, so that the reversal is smooth and reliable. 3. programmable sectional and speed loading. 3. the loading process can be programmed in segments and speeds.
4. motorized adjustment of horizontal loading height, any position self-locking holding position.
BRAND | Great Win |
ITEM NO. | GW-BFM-24 |
ORDER(MOQ) | 1 |
PAYMENT | TT OR L/C |
PRODUCT ORIGIN | China |
SHIPPING PORT | Shenzhen Port |
LEAD TIME | In stock, 7days Fast Delivery |
| Technical Specifications |
| Parameter | 1. can set the guide rail travel: 80-580 mm, can set the maximum push and pull speed: 400 mm / sec. 2. Maximum push and pull force alarm output can be set: 0-25kg force. 3. Motorized adjustable horizontal loading height: 200-1600 mm, self-locking at any height position. 4. Overall dimensions: 1200 * 850 * 1970 mm, 177 kg; Power supply: 220VAC 5A. |
| Control | 1. PLC control, touch screen input test parameters and output test and results. With stop break point memory function. 2. Adopting Panasonic AC servo motor drive, supporting pull pressure sensor. Real-time tracking amount to display the movement position and the size of push and pull force. |
