1. Input the test parameters and output the test results on the touch screen, and display and track the values and curves of each force ~ time in real time. Real-time display and tracking of the values and curves of each force ~ time, etc.
2. adjustable air pressure bar installation height. 3.
3. adopts multi-channel non-contact infrared temperature monitoring and recording system, when the temperature of a channel exceeds the set value, the channel outputs an alarm and stops testing.
GW-BFM-18
Great Win
9024800000
| Quantity: | |
|---|---|
Product Characteristics |
1. Input the test parameters and output the test results on the touch screen, and display and track the values and curves of each force ~ time in real time. Real-time display and tracking of the values and curves of each force ~ time, etc.
2. adjustable air pressure bar installation height. 3.
3. adopts multi-channel non-contact infrared temperature monitoring and recording system, when the temperature of a channel exceeds the set value, the channel outputs an alarm and stops testing.
BRAND | Great Win |
ITEM NO. | GW-BFM-18 |
ORDER(MOQ) | 1 |
PAYMENT | TT OR L/C |
PRODUCT ORIGIN | China |
SHIPPING PORT | Shenzhen Port |
LEAD TIME | In stock, 7days Fast Delivery |
| Technical Specifications |
parameters | 1. Pneumatic bar compression stroke: 60mm (60mm is standard, accept customer non-standard customization). 2 Adopt 50mm diameter cylinder loading, stroke 100mm, maximum output 900N pressure. 3. 3. Adjustable test speed: 10 ~ 25 times / min. 4. 4 real-time recording and tracking temperature curve range: 0-100 ºC, display accuracy: ± 1 ºC. 5. 5. air pressure: ≥ 0.5MPa; flow rate: ≥ 800 liters / min; air source needs to be filtered water and drying. 6. power supply 220VAC, 2A. |
Product Characteristics |
1. Input the test parameters and output the test results on the touch screen, and display and track the values and curves of each force ~ time in real time. Real-time display and tracking of the values and curves of each force ~ time, etc.
2. adjustable air pressure bar installation height. 3.
3. adopts multi-channel non-contact infrared temperature monitoring and recording system, when the temperature of a channel exceeds the set value, the channel outputs an alarm and stops testing.
BRAND | Great Win |
ITEM NO. | GW-BFM-18 |
ORDER(MOQ) | 1 |
PAYMENT | TT OR L/C |
PRODUCT ORIGIN | China |
SHIPPING PORT | Shenzhen Port |
LEAD TIME | In stock, 7days Fast Delivery |
| Technical Specifications |
parameters | 1. Pneumatic bar compression stroke: 60mm (60mm is standard, accept customer non-standard customization). 2 Adopt 50mm diameter cylinder loading, stroke 100mm, maximum output 900N pressure. 3. 3. Adjustable test speed: 10 ~ 25 times / min. 4. 4 real-time recording and tracking temperature curve range: 0-100 ºC, display accuracy: ± 1 ºC. 5. 5. air pressure: ≥ 0.5MPa; flow rate: ≥ 800 liters / min; air source needs to be filtered water and drying. 6. power supply 220VAC, 2A. |
