Using xenon arc lamps that can simulate the whole sunlight spectrum to reproduce the destructive light waves in different environments can provide the corresponding environmental simulation and acceleration tests for scientific research, product development and quality control.
The SN type xenon arc lamp chamber can be used to select new materials, alter existing materials, or evaluate changes in durability after changes in material composition. It can well simulate changes in material exposure to sunlight under different environmental conditions.
The material samples were exposed to xenon arc light and thermal radiation for aging test.
To evaluate the light and weather resistance of some materials under the action of high temperature light source.
GW-051E
Great Win
9024800000
| Quantity: | |
|---|---|
Brief introduction |
Using xenon arc lamps that can simulate the whole sunlight spectrum to reproduce the destructive light waves in different environments can provide the corresponding environmental simulation and acceleration tests for scientific research, product development and quality control.
The SN type xenon arc lamp chamber can be used to select new materials, alter existing materials, or evaluate changes in durability after changes in material composition. It can well simulate changes in material exposure to sunlight under different environmental conditions.
The material samples were exposed to xenon arc light and thermal radiation for aging test.
To evaluate the light and weather resistance of some materials under the action of high temperature light source.
BRAND | Great Win |
ITEM NO. | GW-051E |
ORDER(MOQ) | 1 |
PAYMENT | TT OR L/C |
PRODUCT ORIGIN | China |
SHIPPING PORT | Shenzhen Port |
LEAD TIME | In stock, 7days Fast Delivery |
Professional Technology:
1. Studio size (mm) : 500×500×600(Width × depth × height)
2. Temperature range: 10℃ ~ 80℃
3. Humidity range: light cycle 50% ~ 98% R.H, dark cycle 30% ~ 98%
4. Blackboard temperature: 63℃, 100℃ (deviation ±3℃)
5. Temperature fluctuation: ≤±0.5℃
6. Temperature uniformity: ≤±2.0℃
7. Humidity fluctuation: +2% ~ -3% R.H
8. Glass filter: borosilicate glass
9. Xenon lamp source: imported air-cooled xenon arc light source
10. Xenon lamp Power: 3KW
11. Total number of lamp tubes: 1
12. Rainfall time: 1 ~ 9999 minutes, continuous rainfall is adjustable
13. Rainfall cycle: 1 ~ 240 minutes, interval (break) rainfall can be adjusted
14, water spray nozzle aperture: Ф 0.8 mm (return hose ultra-fine filters to prevent the nozzle blocking)
15. Rain water pressure: 0.12 ~ 0.15 kPa
16. Water-spraying cycle (water-spraying time/non-water-spraying time) : 18min/102min or 12min/48min(water-spraying time/non-water-spraying time) water-spraying pressure is 0.12-0.15mpa
17. Heating power: 3.5KW
18. Humidifying power: 2KW, sample tray size: 600×500mm
19.Machine power:5KW
20. The light cycle can be adjusted continuously for 1-999 hours
21. Spectral wavelength: the irradiance range of 290nm to 800nm is adjustable from 100W to 800W/㎡.
Standrad For:
ASTMG155,ISO10SB02/B04,AATCC16-3,SAEJ2527,GB/T2423.24-1995
