Thank you choose our company's products, the company not only give your company provide high quality products, and will provide reliable after-sales service.
In order to ensure the use of personnel of the personal safety and equipment integrity, before using the instrument, please fully read this operation manual, really pay attention to the use of the matters needing attention.This manual details the design principle of the instrument, according to the standard, structure, operation specification, calibration, maintenance, possible failure conditions and elimination method, electrical diagrams, etc.Is mentioned in this manual, such as the various "test", "standard" are for reference only, if you feel the objection please review standards or data on its own.
GW-141
Great Win
9024800000
| Quantity: | |
|---|---|
Brief introduction |
Thank you choose our company's products, the company not only give your company provide high quality products, and will provide reliable after-sales service.
In order to ensure the use of personnel of the personal safety and equipment integrity, before using the instrument, please fully read this operation manual, really pay attention to the use of the matters needing attention.This manual details the design principle of the instrument, according to the standard, structure, operation specification, calibration, maintenance, possible failure conditions and elimination method, electrical diagrams, etc.Is mentioned in this manual, such as the various "test", "standard" are for reference only, if you feel the objection please review standards or data on its own.
BRAND | Great Win |
ITEM NO. | GW-141 |
ORDER(MOQ) | 1 |
PAYMENT | TT OR L/C |
PRODUCT ORIGIN | China |
SHIPPING PORT | Shenzhen Port |
LEAD TIME | In stock, 7days Fast Delivery |
Technical specifications:
| Pressure range | 0~10kpa |
| Pressure accuracy | 0.5 |
| Volume range | 0~60dm |
| Volume accuracy | accuracy ≤± 1% |
| Inflation rate | (24-30) DM ³/ Min or (0.4 ~ 0.5) DM ³/ S (automatic adjustment) |
| Power supply | 220/110v 50/60hz |
| Air pressure | 0.4~0.5mpa |
| Gas filtration | 0.01mm, no oil, dry |
| Instrument size | 1000mm*500mm*1400m |
•Standrad For:
GB7544-2019,ISO23409,ISO4074:2015,ISO25841:2014,ASTM D6324
